Silicone Insulated Flat Braided Shunt - Solderless Pressed Contact Areas

Construction and Application

These connectors are manufactured from highly flexible tapes, which are braided from annealed Cu-ETP1 wires, and solderless contact areas pressed from seamless Cu-ETP tubes. the braided tapes and tubes are of the same analysis and conductivity.

The best alternative to cable; no cutting, no crimping, flexible, pre-punched, ready to use, quick and easy to install.

Technical Data


  • 0.20 mm annealed Cu-ETP wires, uncoated or tinned.

Contact Areas

  • Solderless pressed seanless Cu-ETP tube.


  • Silicone (UL 758 tested)

Operating Voltage: 1000V AC - 1500V DC
Heat Aging: 250°C 10 days
Minimum Temperature - Cold Bent: -50°C
Dielectric Strength: >21kv/mm
Reaction to Fire: CSE Class 1
Smoke Class Determination: F1

Data Table
